动力源采用伺服电缸，操作便捷、经济高效，广泛应用于汽车制造、电子电器、家电五金、机械装配、新能源、汽车电子、精密制造、航空航天等领域。
动力源采用伺服电缸，操作便捷、经济高效，广泛应用于汽车制造、电子电器、家电五金、机械装配、新能源、汽车电子、精密制造、航空航天等领域。
Equipment powered by servo electric cylinders offers user-friendly operation and delivers cost-effective performance, making it extensively utilized across industries such as automotive manufacturing, electronics and electrical appliances, home appliance hardware, mechanical assembly, new energy, automotive electronics, precision manufacturing, and aerospace.
型号Type | 工作台面积（mm）Worktable area | 最大压力KN Maximum pressure | 定位精度mm Positioning accuracy | 压装速度mm/s Press-fitting speed | 开口高度mm Closed height | 电缸行程mm Electric cylinder stroke | 功率KW Power | 电压Voltage | T型槽T-slot | 安全光栅Safety light curtain | 触摸屏Touchscreen | 底座Base |
HW-SPT0200 | 450*350 | 2 | ±0.02 | 0-125 | 500 | 300 | 0.4 | 220V | M8 | 有With | 7-inch | 无Without |
HW-SPT0500 | 450*350 | 5 | ±0.02 | 0-125 | 500 | 300 | 0.75 | 220V | M8 | 有With | 7-inch | 无Without |
HW-SPT1000 | 450*350 | 10 | ±0.02 | 0-62.5 | 500 | 300 | 0.75 | 220V | M8 | 有With | 7-inch | 无Without |
HW-SPT2000 | 550*500 | 20 | ±0.02 | 0-59 | 500 | 300 | 1.5 | 220V | M10 | 有With | 7-inch | 无Without |
HW-SPT3000 | 550*500 | 30 | ±0.02 | 0-62.5 | 500 | 300 | 2.3 | 220V | M10 | 有With | 7-inch | 无Without |
HW-SPT5000 | 550*500 | 50 | ±0.02 | 0-50 | 500 | 300 | 3 | 380V | M10 | 有With | 7-inch | 无Without |
HW-SPT10000 | 550*500 | 100 | ±0.02 | 0-50 | 500 | 300 | 5.5 | 380V | M12 | 有With | 7-inch | 无Without |
HW-SPT15000 | 550*500 | 150 | ±0.02 | 0-50 | 500 | 300 | 7.5 | 380V | M12 | 有With | 7-inch | 无Without |
HW-SPL0200 | 450*350 | 2 | ±0.02 | 0-125 | 500 | 300 | 0.4 | 220V | M8 | 有With | 7-inch | 有With |
HW-SPL0500 | 450*350 | 5 | ±0.02 | 0-125 | 500 | 300 | 0.75 | 220V | M8 | 有With | 7-inch | 有With |
HW-SPL1000 | 450*350 | 10 | ±0.02 | 0-62.5 | 500 | 300 | 0.75 | 220V | M10 | 有With | 7-inch | 有With |
HW-SPL2000 | 550*500 | 20 | ±0.02 | 0-59 | 500 | 300 | 1.5 | 220V | M10 | 有With | 7-inch | 有With |
HW-SPL5000 | 550*500 | 50 | ±0.02 | 0-50 | 500 | 300 | 3 | 380V | M12 | 有With | 7-inch | 有With |
HW-SPL10000 | 550*500 | 100 | ±0.02 | 0-50 | 500 | 300 | 5.5 | 380V | M12 | 有With | 7-inch | 有With |
HW-SPL20000 | 550*500 | 200 | ±0.02 | 0-41.6 | 500 | 300 | 11 | 380V | M12 | 有With | 7-inch | 有With |
HW-SPL30000 | 550*500 | 200 | ±0.02 | 0-39 | 500 | 300 | 15 | 380V | M12 | 有With | 7-inch | 有With |
